故事

前端时间由于项目需要用到视频上传以及转码,于是自己开始造轮子,之后把那不是很⚪的轮子开源了,有人提了isuss说,上传时候切片过多,会导致卡住,总是在最后几个切片没办法提交成功。于是我f12看了一下,最终没办法解决,增加了socket进行切片上传。

HTTP切片上传出现的问题

在这里插入图片描述
然后查了半天资料说什么因为前端是异步、浏览器什么限制,涉及到协议什么的,然后就不准备折腾了,直接改用socket传输不香么。

撸起袖子加油干

前端代码

 function socketUpload(type,file,dom){
        let name = file.name,        //文件名
            size = file.size;        //总大小

        //socket数据针过大会导致发送断开
        let shardSize = 5 * 1024 * 1024,    //以1MB为一个分片
            shardCount = Math.ceil(size / shardSize);  //总片数

        let GUID = guid();
        let ws = new WebSocket('ws://localhost:8080/file/' + GUID);

        let map = {code:null,type:type,name: null, chunks: null};
        ws.onopen = () => {
            console.log('建立文件上传通道 ...');
            map.chunks = shardCount;
            map.name = name;
            map.code = 0;
            //创建服务器存储目录
            ws.send(JSON.stringify(map));
        }
        ws.onmessage = (evt) => {
            console.log('Received Message: ' + evt.data);
            let parse = JSON.parse(evt.data);
            if (parse.code == 101) {
                console.log('通道已建立 ...');
                for (let i = 0; i < shardCount; ++i) {
                    //计算每一片的起始与结束位置
                    let start = i * shardSize,
                        end = Math.min(size, start + shardSize);
                    let fileBlob = file.slice(start, end);
                    ws.send(fileBlob);
                }
            }
            if (parse.code == 200) {
                document.getElementById(dom).innerHTML = "当前上传进度为:" + parse.msg + "%";
            } else if (parse.code == 202){
                document.getElementById(dom).innerHTML = "文件正在解析";
            } else if (parse.code == 201){
                document.getElementById(dom).innerHTML = "解析成功,地址为:"+parse.data;
                if (type ==='video'){
                    changeVideo(parse.data);
                }
            }else {
                document.getElementById(dom).innerHTML = parse.data;
            }
            return null;
        }
        ws.onclose = function (e) {
            console.log('websocket 断开: ' + e.code + ' ' + e.reason + ' ' + e.wasClean)
            console.log(e)
        }
    }

后端代码

package com.wslhome.demo.api;

import com.alibaba.fastjson.JSONObject;
import com.wslhome.demo.config.FilePath;
import com.wslhome.demo.obj.FileDetail;
import com.wslhome.demo.obj.Result;
import com.wslhome.demo.service.FileService;
import lombok.extern.slf4j.Slf4j;
import org.apache.commons.io.FileUtils;
import org.apache.commons.lang3.StringUtils;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;

import javax.annotation.Resource;
import javax.websocket.*;
import javax.websocket.server.PathParam;
import javax.websocket.server.ServerEndpoint;
import java.io.ByteArrayInputStream;
import java.io.File;
import java.io.IOException;
import java.util.Map;
import java.util.concurrent.ConcurrentHashMap;
import java.util.concurrent.atomic.AtomicInteger;

/**
 * 大文件切片上传改用websocket
 */
@ServerEndpoint(value = "/file/{guid}")
@Controller
@Slf4j
public class FileSocket {
    //统计
    private static AtomicInteger count = new AtomicInteger(0);

    //链接信息
    private static Map<String, FileDetail> fileInfo = new ConcurrentHashMap<>();
    //切片计数
    private static Map<String,AtomicInteger> chunk = new ConcurrentHashMap<>();

    private static FilePath filePath;

    private static FileService fileService;

    @Autowired
    private void setFilePath(FilePath filePath){
        this.filePath = filePath;
    }

    @Autowired
    private void setFileService(FileService fileService){
        this.fileService = fileService;
    }

    String projectUrl = System.getProperty("user.dir").replaceAll("\\\\", "/");



    /**
     * 连接建立成功调用的方法
     */
    @OnOpen
    public void onOpen(Session session) {
        count.incrementAndGet();
        log.info("{} 开始建立大文件上传通道。",session.getId());
        log.info("当前链接数:{}",count.get());
    }

    /**
     * 连接关闭调用的方法
     */
    @OnClose
    public void onClose(Session session,@PathParam("guid") String guid) {
        count.decrementAndGet();
        fileInfo.remove(guid);
        chunk.remove(guid);
        log.info("{} 文件上传通道已关闭",session.getId());
    }

    /**
     * 收到客户端消息后调用的方法
     */
    @OnMessage
    public void onMessage(String message, @PathParam("guid") String guid, Session session){
        if(StringUtils.isBlank(message)){
            return;
        }
        FileDetail fileDetail = JSONObject.parseObject(message, FileDetail.class);
        fileInfo.put(guid,fileDetail);
        // 临时目录用来存放所有分片文件
        String tempFileDir = projectUrl + filePath.getBigPath() + guid;
        File parentFileDir = new File(tempFileDir);
        if (!parentFileDir.exists()) {
            parentFileDir.mkdirs();
        }
        chunk.put(guid,new AtomicInteger(0));
        sendMessage(session,Result.fileBuild());


    }
    @OnMessage
    public void onMessage(byte[] message, @PathParam("guid") String guid, Session session){
        int number = chunk.get(guid).incrementAndGet();
        log.info("当前切片序号:{}",number);
        String tempFileDir = projectUrl + filePath.getBigPath() + guid;
        File tempPartFile = new File(new File(tempFileDir), guid + "_" + (number-1) + ".part");
        try {
            FileUtils.copyInputStreamToFile(new ByteArrayInputStream(message), tempPartFile);
            FileDetail fileDetail = fileInfo.get(guid);
            if (String.valueOf(number).equals(fileDetail.getChunks().toString())){
                //合并文件
                sendMessage(session,Result.fileOver());
                String path;
                if ("video".equals(fileDetail.getType())){
                    path = fileService.uploadVideoMerge(guid, fileDetail.getName());
                }else{
                    path = fileService.uploadMerge(guid, fileDetail.getName());
                }
                sendMessage(session,Result.fileSuccess(path));
                onClose(session,guid);
            }else{
                sendMessage(session,Result.success(String.valueOf((int)((float) number/fileInfo.get(guid).getChunks()*100))));
            }

        }catch (Exception e){
            log.error("文件切片存储失败!当前序号:{},异常原因:{}",number,e.getMessage());
            sendMessage(session,Result.error("文件上传失败"));
            onError(session,guid,e);
        }
    }
    /**
     * 发生错误时调用
     */
    @OnError
    public void onError(Session session,@PathParam("guid") String guid, Throwable error) {
        fileInfo.remove(guid);
        chunk.remove(guid);
        log.error("socket异常:{}",error.getMessage());
    }

    /**
     * 发送消息
     * @param session:
     * @param message:
     */
    public static void sendMessage(Session session, Result message) {
        try {
            session.getBasicRemote().sendText(JSONObject.toJSONString(message));
        } catch (IOException e) {
            log.error("发送消息出错:{}", e.getMessage());
            e.printStackTrace();
        }
    }
}

完整源码

完整源码请查看
码云:https://gitee.com/sirwsl/uploadWheel/
码云:https://gitee.com/sirwsl/uploadWheel/
码云:https://gitee.com/sirwsl/uploadWheel/
